Vertical Machining Centers
1890 Vertical Machining Centers
- * Has high machine tool accuracy and repetitive positioning accuracy, and can achieve precision machining.
- * Has a large stroke and cutting ability, capable of processing large-sized workpieces.
- * Equipped with multi axis control function, capable of cutting in multiple directions simultaneously, improving machining efficiency and accuracy.
| Speicifications | VMC1890 |
|---|---|
| Table size （mm） | 2000×900 |
| Max. worktable load（kg） | 1600 |
| X-axis travel(mm) | 1800 |
| Y-axis travel(mm) | 900 |
| Z-axis travel(mm) | 600 |
| X-axis Fast shift speed(m/min) | 20 |
| Y-axis Fast shift speed(m/min) | 20 |
| Z-axis Fast shift speed(m/min) | 15 |
| Spindle taper hole | BT50-190 |
| Spindle speed (rpm) | 6000 |
| Machine size (mm) | 5000L*3000W*2900H |
| Machine weight (KG) | 14000 |
